3WL air circuit breakers
3.5 External CubicleBUS modules
3WL/3VL circuit breakers with communication capability - PROFIBUS
76 System Manual, 03/2011, A5E01051353-02
3.5.4.2 Technical data
The table below shows the technical data of the digital configurable output module on the
CubicleBUS:
Table 3- 19 Technical data of the digital configurable output module
Operating voltage on the CubicleBUS min./max. (V) 19.2 / 28.8
Current consumption from the CubicleBUS min./max. (mA) 29/39 (250 rel.)
Number of isolated channels per digital output module 6
Max. possible current per channel with 24 V DC relay 2.7
Max. aggregate current (6 channels) relay at
24 V DC/250 V AC/250 V DC (A)
10 / 10 / 2.5
Maximum number of modules on one Cubicle 1
Power loss min./typ./max. (W) 0.74 / 5.4
Dimensions W/H/D (mm) 70 / 86 / 95
Weight (kg)/relay 0.321
Temperature range (°C) – 20 / 60
3.5.5 Analog output module
Via the analog output module, the most important measured values made available via the
CubicleBUS can be output to analog indicator instruments, e.g. rotary coil instruments, in the
control cabinet door. Four channels are available in each analog output module for this
purpose. The signals are available at two physical interfaces, a 4 - 20 mA interface and a 0 -
10 V interface.

Siemens SENTRON VL Series Specifications

General

Rated voltage	Up to 690V AC
Number of poles	1, 2, 3, 4
Standards	IEC 60947-2, UL 489, CSA C22.2 No. 5
Protection functions	Overload, short-circuit, ground fault
Trip Unit Type	Thermal-magnetic, Electronic
