8.6.24 Data set DS 162 device configuration
The table below shows data set 162 that contains the device configuration. The circuit
breaker currently connected can be read out via this data set.
The table below contains the data sets DS162: Device configuration (length 75 bytes, read-
only):
Table 8- 37 Content of data set 162
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 ID number of the COM15 91 COM15 COM20 16 x char 128 —
20 Order number of the circuit breaker (on the
SENTRON VL, this is the order number of
the trip unit)
103 ETU — Format
(103)
160 —
40 Type (metering function, metering function
PLUS)
138 Meter. fct. — Format
(138)
8 —
41 Type of trip unit 412 ETU ETU Format
(412)
5 —
42 Hardware/software version 3VL 423 — ETU 16 x char 128 —
58 Reserved — — — — 96 —
70 Property byte for byte 4 — COM15 COM20 PB 8 —
71 Property byte for byte 20 — ETU — PB 8 —
72 Property byte for byte 40 — Meter. fct. — PB 8 —
73 Property byte for byte 41 — ETU ETU PB 8 —
74 Property byte for byte 42 — ETU ETU PB 8 —
