Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
214 System Manual, 03/2011, A5E01051353-02
8.6.9 Data set DS 73 min. and max. measured values of the voltages
The table below shows the content of data set 73 in which the minimum and maximum
measured values of the voltages are transmitted. It also contains the associated time stamps
for these minimum and maximum measured values.
The table below contains the data sets DS73: Min./max. measured values of the voltages
and the associated time stamps (length 174 bytes, read-only):
Table 8- 22 Content of data set 73
Byte Description Data point Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Minimum phase-to-phase voltage between
phase L1 and L2
205 Meter. fct. — unsigned
int
16 0
2 Maximum phase-to-phase voltage between
phase L1 and L2
206 Meter. fct. — unsigned
int
16 0
4 Minimum phase-to-phase voltage between
phase L2 and L3
207 Meter. fct. — unsigned
int
16 0
6 Maximum phase-to-phase voltage between
phase L2 and L3
208 Meter. fct. — unsigned
int
16 0
8 Minimum phase-to-phase voltage between
phase L3 and L1
209 Meter. fct. — unsigned
int
16 0
10 Maximum phase-to-phase voltage between
phase L3 and L1
210 Meter. fct. — unsigned
int
16 0
12 Minimum of the neutral point voltage
phase L1
211 Meter. fct. — unsigned
int
16 0
14 Maximum of the neutral point voltage
phase L1
212 Meter. fct. — unsigned
int
16 0
16 Minimum of the neutral point voltage
phase L2
213 Meter. fct. — unsigned
int
16 0
18 Maximum of the neutral point voltage
phase L2
214 Meter. fct. — unsigned
int
16 0
20 Minimum of the neutral point voltage
phase L3
215 Meter. fct. — unsigned
int
16 0
22 Maximum of the neutral point voltage
phase L3
216 Meter. fct. — unsigned
int
16 0
24 TS minimum phase-to-phase voltage
between phase L1 and L2
37 COM15 — Time 64 —
32 TS maximum phase-to-phase voltage
between phase L1 and L2
38 COM15 — Time 64 —
40 TS minimum phase-to-phase voltage
between phase L2 and L3
39 COM15 — Time 64 —
48 TS maximum phase-to-phase voltage
between phase L2 and L3
40 COM15 — Time 64 —
56 TS minimum phase-to-phase voltage
between phase L3 and L1
41 COM15 — Time 64 —
64 TS maximum phase-to-phase voltage
between phase L3 and L1
42 COM15 — Time 64 —
