Data library
8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
189
8.5.9 Data points for the time stamp (TS) of the measured values
The table below contains the data points for the time stamp (TS) of the measured values:
Table 8- 9 Data points for the time stamp (TS) of the measured values
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
TS minimum current in phase L1 25 COM15 — Time 64 — DS72.32
TS maximum current in phase L1 26 COM15 — Time 64 — DS72.40
TS minimum current in phase L2 27 COM15 — Time 64 — DS72.48
TS maximum current in phase L2 28 COM15 — Time 64 — DS72.56
TS minimum current in phase L3 29 COM15 — Time 64 — DS72.64
TS maximum current in phase L3 30 COM15 — Time 64 — DS72.72
TS minimum current in neutral conductor 33 COM15 — Time 64 — DS72.112
TS maximum current in neutral conductor 34 COM15 — Time 64 — DS72.120
TS minimum current that flows to ground 35 COM15 — Time 64 — DS72.128
TS maximum current that flows to ground 36 COM15 — Time 64 — DS72.136
TS minimum mean value over the three
phases
31 COM15 — Time 64 — DS72.80
TS maximum mean value over the three
phases
32 COM15 — Time 64 — DS72.88
TS minimum long-term mean value for
current
55 COM15 — Time 64 — DS72.96
TS maximum long-term mean value of
current
56 COM15 — Time 64 — DS72.104
TS minimum phase-to-phase voltage
between phase L1 and L2
37 COM15 — Time 64 — DS73.24
TS maximum phase-to-phase voltage
between phase L1 and L2
38 COM15 — Time 64 — DS73.32
TS minimum phase-to-phase voltage
between phase L2 and L3
39 COM15 — Time 64 — DS73.40
TS maximum phase-to-phase voltage
between phase L2 and L3
40 COM15 — Time 64 — DS73.48
TS minimum phase-to-phase voltage
between phase L3 and L1
41 COM15 — Time 64 — DS73.56
TS maximum phase-to-phase voltage
between phase L3 and L1
42 COM15 — Time 64 — DS73.64
TS minimum of the neutral point voltage
phase L1
43 COM15 — Time 64 — DS73.72
TS maximum of the neutral point voltage
phase L1
44 COM15 — Time 64 — DS73.80
TS minimum of the neutral point voltage
phase L2
45 COM15 — Time 64 — DS73.88
TS maximum of the neutral point voltage
phase L2
46 COM15 — Time 64 — DS73.96
TS minimum of the neutral point voltage
phase L3
47 COM15 — Time 64 — DS73.104
