8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
185
8.5.7 Data points for measured values power
The table below contains the data points for measured values power:
Table 8- 7 Data points for measured values power
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
Total apparent power 217 Meter. fct. — unsigned
int
16 0 DS94.40
Apparent power in phase L1 218 Meter. fct. — unsigned
int
16 0 DS94.62
Apparent power in phase L2 219 Meter. fct. — unsigned
int
16 0 DS94.64
Apparent power in phase L3 220 Meter. fct. — unsigned
int
16 0 DS94.66
Total active power 221 Meter. fct. — signed int 16 0 DS94.42
Active power in phase L1 222 Meter. fct. — signed int 16 0 DS94.44
Active power in phase L2 223 Meter. fct. — signed int 16 0 DS94.46
Active power in phase L3 224 Meter. fct. — signed int 16 0 DS94.48
Total reactive power 225 Meter. fct. — signed int 16 0 DS94.50
Reactive power in phase L1 226 Meter. fct. — signed int 16 0 DS94.76
Reactive power in phase L2 227 Meter. fct. — signed int 16 0 DS94.78
Reactive power in phase L3 228 Meter. fct. — signed int 16 0 DS94.80
Long-time mean value of 3-phase active
power
229 Meter. fct. — signed int 16 0 DS94.52
Long-time mean value of active power in
phase L1
230 Meter. fct. — signed int 16 0 DS94.54
Long-time mean value of active power in
phase L2
231 Meter. fct. — signed int 16 0 DS94.56
Long-time mean value of active power in
phase L3
232 Meter. fct. — signed int 16 0 DS94.58
Long-time mean value of 3-phase
apparent power
233 Meter. fct. — unsigned
int
16 0 DS94.60
Long-time mean value of apparent
power in phase L1
234 Meter. fct. — unsigned
int
16 0 DS94.68
Long-time mean value of apparent
power in phase L2
235 Meter. fct. — unsigned
int
16 0 DS94.70
Long-time mean value of apparent
power in phase L3
236 Meter. fct. — unsigned
int
16 0 DS94.72
Long-time mean value of 3-phase
reactive power
237 Meter. fct. — signed int 16 0 DS94.74
Minimum of the mean value of the
apparent power
246 Meter. fct. — unsigned
int
16 0 DS74.4
Maximum of the mean value of the
apparent power
247 Meter. fct. — unsigned
int
16 0 DS74.6
Minimum of the mean value of the
reactive power
248 Meter. fct. — signed int 16 0 DS74.12
