Data library
8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
270 System Manual, 03/2011, A5E01051353-02
Table 8- 64 Format (145) "Direction of incoming supply"
Byte Value Meaning
0 0 From top to bottom
0 1 From bottom to top
The table below shows the format (146) "Direction of rotation of phase". The normal status of
the direction of rotation of the phase can be set using this.
Table 8- 65 Format (146) "Direction of rotation of phase"
Byte Value Meaning
0 0 Right (e.g. L1 – L2 – L3)
0 1 Left (e.g. L1 – L3 – L2 or similar)
The table below shows the format (162) "Voltage transformer". The setting of the primary
connection also influences the location of the measured voltage variables.
Table 8- 66 Format (162) "Voltage transformer"
Byte Value Meaning
0 0 The voltage transformer is delta-connected on the primary side.
0 1 The voltage transformer is star-connected on the primary side.
8.7.6 Data formats 307 to 373
The table below shows the format (307) "Tripping of the metering function" that displays the
content of the last tripping operation by the extended protection function.
Table 8- 67 Format (307) "Tripping of the metering function"
Byte Value Meaning
0/1 0x0000 No tripping operation
0/1 0x0001 Phase unbalance current
0/1 0x0002 Phase unbalance voltage
0/1 0x0004 Active power in normal direction
0/1 0x0008 Active power in reverse direction
0/1 0x0040 Overvoltage
0/1 0x0080 Undervoltage
0/1 0x0100 Overfrequency
0/1 0x0200 Underfrequency
0/1 0x0400 THD current
0/1 0x0800 THD voltage
0/1 0x1000 Change of phase rotation
The table below shows the format (308) "Threshold alarms" that displays the currently
pending threshold alarms.
