Data library
8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
269
Byte Value Meaning
0 0x3F PROFIBUS bit 2 (#426)
0 0x40 PROFIBUS bit 3 (#426)
0 0x41 PROFIBUS bit 4 (#426)
0 0x42 PROFIBUS bit 5 (#426)
0 0x43 PROFIBUS bit 6 (#426)
1 — 2. event at the 1st output
2 — 3. event at the 1st output
3 — 4. event at the 1st output
4 — 5. event at the 1st output
5 — 6. event at the 1st output
6 — 1. event at the 2nd output
7 — 2. event at the 2nd output
8 — 3. event at the 2nd output
9 — 4. event at the 2nd output
10 — 5. event at the 2nd output
11 — 6. event at the 2nd output
12 — 1. event at the 3rd output
13 — 2. event at the 3rd output
14 — 3. event at the 3rd output
15 — 4. event at the 3rd output
16 — 5. event at the 3rd output
17 — 6. event at the 3rd output
18 — Event at the 4th output
19 — Event at the 5th output
20 — Event at the 6th output
The table below shows the format (138) "Type of the metering function". It specifies which
type of metering function is built in.
Table 8- 63 Format (138) "Type of the metering function"
Byte Value Meaning
0 0x00 No metering function
0 0x02 Metering function
0 0x03 Metering function PLUS
The table below shows the format (145) "Direction of incoming supply". The sign for active
power and reactive power depend on the "Direction of incoming supply".
