8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
268 System Manual, 03/2011, A5E01051353-02
Byte Value Meaning
0 0x15 Trip: Ground fault G
0 0x16 Trip: Overload N-conductor N
0 0x17 Trip: Phase unbalance current
0 0x18 Trip: Phase unbalance voltage
0 0x19 Trip: Underfrequency
0 0x1A Trip: Overfrequency
0 0x1B Trip: Undervoltage
0 0x1C Trip: Overvoltage
0 0x1D Trip: Active power in normal direction
0 0x1E Trip: Active power in reverse direction
0 0x1F Trip: THD current
0 0x20 Trip: THD voltage
0 0x21 Trip: Reverse direction of rotation of phase
0 0x22 Threshold value TV: Overcurrent
0 0x23 TV: Overcurrent N-conductor
0 0x24 TV: Overcurrent ground fault
0 0x25 TV: Phase unbalance current
0 0x26 TV: Phase unbalance voltage
0 0x27 TV: Long-term av. Current
0 0x28 TV: Undervoltage
0 0x29 TV: Overvoltage
0 0x2A TV: THD current
0 0x2B TV: THD voltage
0 0x2C TV: Peak factor
0 0x2D TV: Form factor
0 0x2E TV: Underfrequency
0 0x2F TV: Overfrequency
0 0x30 TV: Active power in normal direction
0 0x31 TV: Active power in reverse direction
0 0x32 TV: Apparent power
0 0x33 TV: Reactive power in normal direction
0 0x34 TV: Reactive power in reverse direction
0 0x35 TV: cos φ capacitive
0 0x36 TV: cos φ inductive
0 0x37 TV: Long-time mean value of active power
0 0x38 TV: Long-time mean value of reactive power
0 0x39 TV: Long-time mean value of apparent power
0 0x3A Trigger event A occurred
0 0x3B Trigger event B occurred
0 0x3C Parameter set A active
0 0x3D Parameter set B active
0 0x3E PROFIBUS bit 1 (#426)
