Data library
8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
267
Table 8- 61 Format (121) "Control DO outputs"
Byte Value Meaning
0 0 No action
0 1 Set output 1 ("1")
0 2 Reset output 1 ("0")
0 3 Set output 2 ("1")
0 4 Reset output 2 ("0")
0 5 Set output 3 ("1")
0 6 Reset output 3 ("0")
0 7 Set output 4 ("1")
0 8 Reset output 4 ("0")
0 9 Set output 5 ("1")
0 10 Reset output 5 ("0")
0 11 Set output 6 ("1")
0 12 Reset output 6 ("0")
0 13 Switch force mode off (overwriting of the actually valid data)
The table below shows the format (129) "Configurable output module". Event 1 of the 1st
output provides an example of the assignment for all others.
Table 8- 62 Format (129) "Configurable output module"
Byte Value Meaning
0 — 1. event at the 1st output
0 0x00 Not assigned
0 0x01 Switch on
0 0x02 Switch off
0 0x03 Spring energy store compressed
0 0x04 Ready for switching on
0 0x05 General warning
0 0x06 Group tripped signal
0 0x07 DP write protection active
0 0x08 DP communication OK
0 0x09 Alarm: Overload
0 0x0A Alarm: Overload N-conductor
0 0x0B Alarm: Load shedding
0 0x0C Alarm: Ground fault
0 0x0D Alarm: Overtemperature
0 0x0E Alarm: µP-Error
0 0x0F Alarm: Phase unbalance Current
0 0x10 Alarm: Load pick up
0 0x11 Trip: Overload L
0 0x12 Trip: Delayed short-circuit I
0 0x13 Trip: Instantaneous Short-circuit S
