8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
251
8.6.23 Data set DS 160 Parameters for communication
The following table shows data set 160, in which the parameters for communication are
stored. These parameters can be read and also set via this data set.
The table contains the data sets DS160: Parameters for communication (length 77 bytes,
read/write):
Table 8- 36 Content of data set 160
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 Reserved — — — — 8 —
5 PROFIBUS address 5 COM15 COM20 unsigned c
har
8 0
6 Basic type of PROFIBUS data transfer 6 COM15 COM20 Hex 2 —
7 Reserved — — — — 8 —
8 Data in the cyclic profile of PROFIBUS 7 COM15 COM20 Format (7) 224 —
36 Reserved — — — — 48 —
42 IP address of the BDA PLUS 10 BDA PLU
S
— Format
(10)
40 —
48 Reserved — — — — 176 —
70 Reserved — — — — 8 —
71 Property byte for byte 5 — COM15 COM20 PB 8 —
72 Property byte for byte 6 — COM15 COM20 PB 8 —
73 Reserved — — — PB 8 —
74 Property byte for byte 8 — COM15 COM20 PB 8 —
75 Reserved — — — PB 8 —
76 Property byte for byte 42 — BDA PLU
S
— PB 8 —
