Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
243
8.6.21 Data set DS 130 Parameters for the threshold values
The table below shows the DS130 via which the parameters for generating threshold alarms
can be read out and modified.
The table contains the data sets DS130: Parameters for the threshold values (length
148 bytes, read/write) Part 1:
Table 8- 34 Content of data set 130
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 Active power in normal direction 283 Meter. fct. — unsigned
int
16 0
6 Active power in reverse direction 285 Meter. fct. — unsigned
int
16 0
8 Power factor, capacitive 287 Meter. fct. — signed int 16 –3
10 Power factor, inductive 289 Meter. fct. — signed int 16 –3
12 Delay time for active power in normal
direction
284 Meter. fct. — unsigned c
har
8 0
13 Delay time for active power in reverse
direction
286 Meter. fct. — unsigned c
har
8 0
14 Delay time for power factor, capacitive 288 Meter. fct. — unsigned c
har
8 0
15 Delay time for power factor, inductive 290 Meter. fct. — unsigned c
har
8 0
16 Overfrequency 303 Meter. fct. — unsigned c
har
8 0
17 Delay time for overfrequency 304 Meter. fct. — unsigned c
har
8 0
18 Underfrequency 305 Meter. fct. — unsigned c
har
8 0
19 Delay time for underfrequency 306 Meter. fct. — unsigned c
har
8 0
20 THD current 319 Meter. fct. — unsigned c
har
8 0
21 Delay time for THD current 320 Meter. fct. — unsigned c
har
8 0
22 THD voltage 321 Meter. fct. — unsigned c
har
8 0
23 Delay time for THD voltage 322 Meter. fct. — unsigned c
har
8 0
24 Peak factor 323 Meter. fct. — unsigned
int
16 –2
26 Form factor 325 Meter. fct. — unsigned
int
16 –2
28 Delay time for peak factor 324 Meter. fct. — unsigned c
har
8 0
