Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
244 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
29 Delay time for the form factor 326 Meter. fct. — unsigned c
har
8 0
30 Long-time mean value of active power 291 Meter. fct. — unsigned
int
16 0
32 Long-time mean value of apparent power 293 Meter. fct. — unsigned
int
16 0
34 Delay time for long-term mean value of active
power
292 Meter. fct. — unsigned c
har
8 0
35 Delay time for long-term mean value of
apparent power
294 Meter. fct. — unsigned c
har
8 0
36 Long-time mean value of reactive power 295 Meter. fct. — unsigned
int
16 0
38 Reactive power in normal direction 297 Meter. fct. — unsigned
int
16 0
40 Delay time for long-term mean value of
reactive power
296 Meter. fct. — unsigned c
har
8 0
41 Delay time for reactive power in normal
direction
298 Meter. fct. — unsigned c
har
8 0
42 Reactive power in reverse direction 299 Meter. fct. — unsigned
int
16 0
44 Apparent power 301 Meter. fct. — unsigned
int
16 0
46 Delay time for reactive power in reverse
direction
300 Meter. fct. — unsigned c
har
8 0
47 Delay time for apparent power 302 Meter. fct. — unsigned c
har
8 0
48 Overcurrent 267 Meter. fct. — unsigned
int
16 0
50 Current that flows to ground 269 Meter. fct. — unsigned
int
16 0
52 Overcurrent in neutral conductor 271 Meter. fct. — unsigned
int
16 0
54 Long-time mean value of current 275 Meter. fct. — unsigned
int
16 0
56 Delay time for overcurrent 268 Meter. fct. — unsigned c
har
8 0
57 Delay time of current that flows to ground 270 Meter. fct. — unsigned c
har
8 0
58 Delay time for overcurrent in neutral
conductor
272 Meter. fct. — unsigned c
har
8 0
59 Phase unbalance current 273 Meter. fct. — unsigned c
har
8 0
60 Delay time for current phase unbalance 274 Meter. fct. — unsigned c
har
8 0
61 Delay time for long-time mean value of
current
276 Meter. fct. — unsigned c
har
8 0
