Siemens SENTRON VL Series System Manual

Data transfer to the PLC
7.1 Interface to S7-300 and control/diagnosis via PROFIBUS
3WL/3VL circuit breakers with communication capability - PROFIBUS
152 System Manual, 03/2011, A5E01051353-02
Step 6
Following this, the data can be transferred to the S7. To do so, use the menu command
"Target System > Load to Module".
The subsequent dialog box must be checked for the correct controller.
You have now completed the configuration for the hardware.
The HW Config program can now be closed.
Note
Before doing this, the setting for the connection to the CPU may have to be set
Interface setting for initial configuration of a CPU via MPI (Page 152)
7.1.3 Interface setting for initial configuration of a CPU via MPI
Step 1 Set PG/PC interface
Select the setting dialog box via SIMATIC Manager
"Options > Set PG/PC Interface"
Select "Interface Parameter Assignment Used" for the connection to the S7 controller, e.g.
● CP5611(MPI)
● CP5613(MPI)
● CP5511(MPI)
● CP5512(MPI)
The standard settings for the transmission rate (187.5 Kbit/s) and highest station address
(15) should not be changed. Any address can be selected.
