8.6.8 Data set DS 72 min. and max. measured values
The table below shows the content of data set 72 in which the minimum and maximum
measured values of the currents are transmitted. It also contains the associated time stamps
for these minimum and maximum measured values.
The table below contains the data sets DS72: Min./max. measured values of the currents
and the associated time stamps (length 236 bytes, read-only):
Table 8- 21 Content of data set 72
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Minimum current in phase 1 384 ETU — unsigned
int
16 0
2 Maximum current in phase 1 385 ETU — unsigned
int
16 0
4 Minimum current in phase 2 386 ETU — unsigned
int
16 0
6 Maximum current in phase 2 387 ETU — unsigned
int
16 0
8 Minimum current in phase 3 388 ETU — unsigned
int
16 0
10 Maximum current in phase 3 389 ETU — unsigned
int
16 0
12 Minimum current in neutral conductor 390 ETU — unsigned
int
16 0
14 Maximum current in neutral conductor 391 ETU ETU unsigned
int
16 0
16 Minimum current which flows to ground 392 ETU — unsigned
int
16 0
18 Maximum current which flows to ground 393 ETU ETU unsigned
int
16 0
20 Minimum mean value over the three phases 394 ETU — unsigned
int
16 0
22 Maximum mean value over the three phases 395 ETU ETU unsigned
int
16 0
24 Minimum long-term mean value for current 244 Meter.
fct.
— unsigned
int
16 0
26 Maximum long-term mean value for current 245 Meter.
fct.
ETU unsigned
int
16 0
28 Minimum peak factor 263 Meter.
fct.
— unsigned c
har
8 –1
29 Maximum peak factor 264 Meter.
fct.
— unsigned c
har
8 –1
30 Minimum form factor 265 Meter.
fct.
— unsigned c
har
8 –1
31 Maximum of the form factor 266 Meter.
fct.
— unsigned c
har
8 –1
32 TS minimum current in phase L1 25 COM15 — Time 64 —
