8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
211
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
40 TS maximum current in phase L1 26 COM15 — Time 64 —
48 TS minimum current in phase L2 27 COM15 — Time 64 —
56 TS maximum current in phase L2 28 COM15 — Time 64 —
64 TS minimum current in phase L3 29 COM15 — Time 64 —
72 TS maximum current in phase L3 30 COM15 — Time 64 —
80 TS minimum mean value over the three
phases
31 COM15 — Time 64 —
88 TS maximum mean value over the three
phases
32 COM15 — Time 64 —
96 TS minimum long-term mean value for current 55 COM15 — Time 64 —
104 TS maximum long-term mean value of current 56 COM15 — Time 64 —
112 TS minimum current in neutral conductor 33 COM15 — Time 64 —
120 TS maximum current in neutral conductor 34 COM15 — Time 64 —
128 TS minimum current that flows to ground 35 COM15 — Time 64 —
136 TS maximum current that flows to ground 36 COM15 — Time 64 —
144 TS minimum peak factor 65 COM15 — Time 64 —
152 TS maximum peak factor 66 COM15 — Time 64 —
160 TS minimum form factor 67 COM15 — Time 64 —
168 TS maximum form factor 68 COM15 — Time 64 —
176 Reserved — — — — 192 —
200 Property byte for byte 0 (minimum current in
phase 1)
— ETU — PB 8 —
201 Property byte for byte 2 (maximum current in
phase 1)
— ETU — PB 8 —
202 Property byte for byte 4 (minimum current in
phase 2)
— ETU — PB 8 —
203 Property byte for byte 6 (maximum current in
phase 2)
— ETU — PB 8 —
204 Property byte for byte 8 (minimum current in
phase 3)
— ETU — PB 8 —
205 Property byte for byte 10 (maximum current in
phase 3)
— ETU — PB 8 —
206 Property byte for byte 12 (minimum current in
neutral conductor)
— ETU — PB 8 —
207 Property byte for byte 14 (maximum current in
neutral conductor)
— ETU ETU PB 8 —
208 Property byte for byte 16 (minimum current
that flows to ground)
— ETU — PB 8 —
209 Property byte for byte 18 (maximum current
that flows to ground)
— ETU ETU PB 8 —
210 Property byte for byte 20 (minimum mean
value over the three phases)
— ETU — PB 8 —
211 Property byte for byte 22 (maximum mean
value over the three phases)
— ETU ETU PB 8 —
