Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
212 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
212 Property byte for byte 24 (minimum current
long-term mean value)
— Meter.
fct.
— PB 8 —
213 Property byte for byte 26 (maximum current
long-term mean value)
— Meter.
fct.
ETU PB 8 —
214 Property byte for byte 28 (minimum of the
peak factor)
— Meter.
fct.
— PB 8 —
215 Property byte for byte 29 (maximum of the
peak factor)
— Meter.
fct.
— PB 8 —
216 Property byte for byte 30 (minimum of the form
factor)
— Meter.
fct.
— PB 8 —
217 Property byte for byte 31 (maximum of the
form factor)
— Meter.
fct.
— PB 8 —
218 Property byte for byte 32 (TS minimum current
in phase 1)
— COM15 — PB 8 —
219 Property byte for byte 40 (TS maximum
current in phase L1)
— COM15 — PB 8 —
220 Property byte for byte 48 (TS minimum current
in phase L2)
— COM15 — PB 8 —
221 Property byte for byte 56 (TS maximum
current in phase L2)
— COM15 — PB 8 —
222 Property byte for byte 64 (TS minimum current
in phase L3)
— COM15 — PB 8 —
223 Property byte for byte 72 (TS maximum
current in phase L3)
— COM15 — PB 8 —
224 Property byte for byte 80 (TS minimum mean
value over the three phases)
— COM15 — PB 8 —
225 Property byte for byte 88 (TS maximum mean
value over the three phases)
— COM15 — PB 8 —
226 Property byte for byte 96 (TS minimum current
long-term mean value)
— COM15 — PB 8 —
227 Property byte for byte 104 (TS maximum
current long-term mean value)
— COM15 — PB 8 —
228 Property byte for byte 112 (TS minimum
current in neutral conductor)
— COM15 — PB 8 —
229 Property byte for byte 120 (TS maximum
current in neutral conductor)
— COM15 — PB 8 —
230 Property byte for byte 128 (TS minimum
current that flows to ground)
— COM15 — PB 8 —
231 Property byte for byte 136 (TS maximum
current that flows to ground)
— COM15 — PB 8 —
232 Property byte for byte 144 (TS minimum of the
peak factor)
— COM15 — PB 8 —
233 Property byte for byte 152 (TS maximum of the
peak factor)
— COM15 — PB 8 —
