8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
222 System Manual, 03/2011, A5E01051353-02
8.6.13 Data set DS 91 statistical information
The table below shows the content of data set 91 in which the statistical information on the
SENTRON circuit breakers is transmitted. As with the other data sets, the property of each
data point is additionally transmitted in the property byte.
The table below contains the data sets DS91: Statistical information (length 84 bytes, read-
only):
Table 8- 26 Content of data set 91
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Number of switching operations under load 80 COM15 COM20 unsigned
int
16 0
2 Number of switching operations caused by
trips
81 COM15 COM20 unsigned
int
16 0
4 Switching cycle counter
(for switching cycle on/off)
82 COM15 — unsigned
int
16 0
6 Runtime meter
(when On + current > 0)
83 COM15 COM20 unsigned
long
32 0
10 Date of the last parameter change 84 COM15 — Time 64 —
18 Number of short-circuit releases (SI) 104 ETU COM20 unsigned
int
16 0
20 Number of overload trips (L) 105 ETU COM20 unsigned
int
16 0
22 Number of ground-fault tripping operations
(G)
106 ETU COM20 unsigned
int
16 0
24 Total of deactivated I²t values L1, L2, L3, N 107 ETU — Format
(107)
128 0
40 Maintenance information about the main
contacts
405 ETU — Format
(405)
2 —
41 Reserved — — — — 56 —
48 Modules connected to c 88 COM15 — Format
(88)
32 —
52 Reserved — — — — 144 —
70 Property byte for byte 0 (number of switching
operations under load)
— COM15 COM20 PB 8 —
71 Property byte for byte 2 (number of switching
operations caused by trips)
— COM15 COM20 PB 8 —
72 Property byte for byte 4 (switching cycle
counter (for switching cycle on/off))
— COM15 — PB 8 —
73 Property byte for byte 6 (runtime meter
(when On + current > 0))
— COM15 COM20 PB 8 —
74 Property byte for byte 10 (date of last
parameter change)
— COM15 — PB 8 —
75 Property byte for byte 18 (number of short-
circuit tripping operations (SI))
— ETU COM20 PB 8 —
76 Property byte for byte 20 (number of overload
trips (L))
— ETU COM20 PB 8 —
