3WL/3VL circuit breakers with communication capability - PROFIBUS
226 System Manual, 03/2011, A5E01051353-02
8.6.15 Data set DS 93 controlling the circuit breakers
The table below shows DS93 via which the SENTRON circuit breakers are switched on, the
min./max. buffer deleted, the outputs of the digital output modules forced, and the 6 available
PROFIBUS bits (can be output via the configurable digital output module) are set.
The table below contains the data sets DS93: Controlling the circuit breakers (length
27 bytes, write-only):
Table 8- 28 Content of data set 93
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 Controls the trip unit 406 ETU ETU Format
(406)
16 —
6 Reserved — — — unsigned c
har
16 —
8 Controls the digital output module 1 121 DO1 — Format
(121)
8 —
9 Controls the digital output module 2 126 DO2 — Format
(121)
8 —
10 Controls the buffers (e.g. min./max. values)
of the communication module
18 COM15 COM20 Format
(18)
8 —
11 Controls the outputs of the communication
module (e.g. switching the breaker)
19 COM15 COM20 Format
(19)
8 —
12 Reserved — — — unsigned c
har
8 —
13 6 PROFIBUS bits for the digital configurable
output module
426 COM15 — Format
(426)
6 —
14 Reserved — — — unsigned c
har
40 —
19 Property byte for byte 13 (6 PROFIBUS bits
for the digital configurable output module)
— COM15 — PB 8 —
20 Property byte for byte 4 (controls the trip unit) — ETU ETU PB 8 —
21 Property byte for byte 6 (reserved) — Meter. fct. — PB 8 —
22 Property byte for byte 8 (controls digital
output module 1)
— DO1 — PB 8 —
23 Property byte for byte 9 (controls digital
output module 2)
— DO2 — PB 8 —
24 Property byte for byte 10 (controls the buffers
(e.g. min./max. values) of the communication
module)
— COM15 COM20 PB 8 —
25 Property byte for byte 11 (controls the
outputs of the communication module (e.g.
switching the breaker))
— COM15 COM20 PB 8 —
26 Reserved — — — unsigned c
har
8 —
