8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
225
Byte Description Data
point
Source
WL
Source VL Format Length
(bits)
Scaling
40 Status of the circuit breaker (on/off/powered,
etc.)
328 BSS COM20 Format
(328)
8 —
41 Reserved — — — unsigned c
har
8 —
42 Event log of the last 10 events with time 16 COM15 — Format
(16)
960 —
162 Reserved — — — unsigned c
har
144 —
180 Property byte for byte 20 (modules connected
to the CubicleBUS)
— COM15 — PB 8 —
181 Property byte for byte 24 (currently pending
alarms)
— ETU ETU PB 8 —
182 Property byte for byte 26 (last
unacknowledged tripping operation of the trip
unit)
— ETU ETU PB 8 —
183 Property byte for byte 28 (tripping operations
by metering function/metering function PLUS)
— Meter. fct. — PB 8 —
184 Property byte for byte 30 (threshold value
warnings)
— Meter. fct. — PB 8 —
185 Property byte for byte 34 (current at the
moment of shutdown)
— ETU ETU PB 8 —
186 Property byte for byte 36 (phase at the
moment of shutdown)
— ETU ETU PB 8 —
187 Property byte for byte 37 (position of the
circuit breaker in the frame)
— COM15 COM20 PB 8 —
188 Reserved — — — unsigned c
har
8 —
189 Property byte for byte 40 (status of the circuit
breaker (on/off/charged, etc.))
— BSS ETU PB 8 —
190 Property byte for byte 42 (event log of the last
10 events with time)
— COM15 COM20 PB 8 —
191 Reserved — — — unsigned c
har
24 —
