Data library
8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
264 System Manual, 03/2011, A5E01051353-02
8.7.5 Data formats 88 to 162
The table below shows the format (88) "CubicleBUS modules" that contains the modules
connected on the CubicleBUS.
Table 8- 52 Format (88) "CubicleBUS modules"
Byte Bit Meaning
0 0 COM15
0 1 Trip unit ETU
0 2 ZSI module
1 0 Configurable digital output module
1 2 Digital output module #2
1 3 Digital input module #2
1 4 Breaker Status Sensor BSS
1 5 Digital output module #1
1 6 Digital input module #1
2 1 BDA PLUS
2 3 Graphic display ETU76B
2 4 Analog output module #2
2 5 Analog output module #1
2 6 Metering function or M. PLUS
The table below shows the format (95) "Market" specifying the market for which the circuit
breaker has been built and tested.
Table 8- 53 Format (95) "Market"
Byte Value Meaning
0 1 IEC
0 2 UL
0 3 ANSI
The table below shows the format (99) "Switching capacity class" that specifies the
maximum level of the breaking current.
Table 8- 54 Format (99) "Switching capacity class"
Byte Value Meaning
0 2 ECO switching capacity N/IntClassN
0 3 Standard switching capacity S/IntClassS
0 4 High switching capacity H/IntClassH
0 5 Extremely high switching capacity C/IntClassC
The table below shows the format (100) "Size". The size is determined by the rated switch
current and the switching capacity class.
