Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
234 System Manual, 03/2011, A5E01051353-02
8.6.18 Data set DS 100 identification overview
The table below shows data set 100 that contains the identification of the relevant switch
(test data, manufacturer, device name or family, device class, etc.).
The table below contains the data sets DS100: Identification overview (length 100 bytes,
read-only):
Table 8- 31 Content of data set 100
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 Test date of switch 98 ETU — PROFIBUS
time
64 —
12 Manufacturer (SIEMENS or SE&A) — COM15 COM20 20 x char 160 —
32 Device name (SENTRON WL or
SENTRON VL)
— COM15 COM20 24 x char 192 —
56 Device family (fixed value 0x03) — COM15 COM20 hex 8 —
57 Device bus family (fixed value 0x01) — COM15 COM20 hex 8 —
58 Device class
(1 = air circuit breaker; 2 = compact circuit
breaker)
— COM15 COM20 hex 8 —
59 System (fixed value 0x06) — COM15 COM20 hex 8 —
60 Function group
(Bit .0 for COM15)
— COM15 COM20 hex 8 —
61 Reserved — — — — 8 —
62 Abbreviated designation (PCB or MCCB) — COM15 COM20 16 x char 128 —
78 HW version — COM15 COM20 4 x char 32 —
82 PROFIBUS identification number
(0x00 00 80 C0)
— COM15 COM20 hex 32 —
86 Reserved — — — — 16 —
88 Service number (lower part of switch
identification number)
— COM15 COM20 8 x char 64 —
96 Firmware version of PROFIBUS module — COM15 COM20 4 x char 32 —
