8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
233
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
186 Reserved — — — — 112 —
200 Property byte for byte 0 (order number of trip
unit)
— ETU — PB 8 —
201 Property byte for byte 18 (date of manufacture
of trip unit)
— ETU — PB 8 —
202 Property byte for byte 26 (identification
number of trip unit)
— ETU ETU PB 8 —
203 Property byte for byte 44 (ground fault
transformer detection method)
— ETU ETU PB 8 —
204 Property byte for byte 45 (N transformer
connected)
— ETU ETU PB 8 —
205 Reserved — — — — 8 —
206 Property byte for byte 47 (market in which the
trip unit is used)
— ETU ETU PB 8 —
207 Property byte for byte 48 (identification
number of circuit breaker)
— ETU — PB 8 —
208 Reserved — — — — 8 —
209 Property byte for byte 74 (test date for switch) — ETU — PB 8 —
210 Property byte for byte 82 (switching capacity
class)
— ETU — PB 8 —
211 Property byte for byte 83 (size) — ETU — PB 8 —
212 Property byte for byte 84 (rated voltage (LL) of
circuit breaker)
— ETU — PB 8 —
213 Property byte for byte 86 (rated current of
external g transformer)
— ETU — PB 8 —
214 Property byte for byte 88 (order number of
circuit breaker (trip unit VL))
— ETU — PB 8 —
215 Reserved — — — — 8 —
216 Property byte for byte 126 (order number of
trip unit)
— ETU — PB 8 —
217 Property byte for byte 144 (number of poles of
circuit breaker)
— ETU ETU PB 8 —
218 Property byte for byte 146 (rating plug) — ETU ETU PB 8 —
219 Property byte for byte 148 (circuit breaker
frame)
— ETU ETU PB 8 —
220 Reserved — — — — 8 —
221 Property byte for byte 154 (order number
COM10)
— — — PB 8 —
222 Property byte for byte 170 (serial number
COM10)
— — COM20 PB 8 —
