Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
219
8.6.11 Data set DS 76 min. and max. measured values of the frequency and the THD
The table below shows the content of data set 76 in which the minimum and maximum
measured values of the frequency and the THD are transmitted. It also contains the
associated time stamps for these minimum and maximum measured values.
The table below contains the data sets DS76: Min./max. measured values of the
frequency/THD and the associated time stamps (length 92 bytes, read-only):
Table 8- 24 Content of data set 76
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Maximum frequency 253 Meter. fct. — unsigned
int
16 – 2
2 Minimum frequency 252 Meter. fct. — unsigned
int
16 – 2
4 Minimum THD of current 255 Meter. fct. — unsigned
char
8 0
5 Maximum THD of current 256 Meter. fct. — unsigned
char
8 0
6 Minimum THD of voltage 258 Meter. fct. — unsigned
char
8 0
7 Maximum THD of voltage 259 Meter. fct. — unsigned
char
8 0
8 TS minimum frequency 59 COM15 — Time 64 —
16 TS maximum frequency 60 COM15 — Time 64 —
24 TS minimum THD of current 61 COM15 — Time 64 —
32 TS maximum THD of current 62 COM15 — Time 64 —
40 TS minimum THD of voltage 63 COM15 — Time 64 —
48 TS maximum THD of voltage 64 COM15 — Time 64 —
56 Reserved — — — — 192 —
80 Property byte for byte 0 (maximum of the
frequency)
— Meter. fct. — PB 8 —
81 Property byte for byte 2 (minimum of the
frequency)
— Meter. fct. — PB 8 —
82 Property byte for byte 4 (minimum of the THD
of current)
— Meter. fct. — PB 8 —
83 Property byte for byte 5 (maximum of the
THD of current)
— Meter. fct. — PB 8 —
84 Property byte for byte 6 (minimum of the THD
of voltage)
— Meter. fct. — PB 8 —
85 Property byte for byte 7 (maximum of the
THD of voltage)
— Meter. fct. — PB 8 —
86 Property byte for byte 8 (TS minimum of the
frequency)
— COM15 — PB 8 —
87 Property byte for byte 16 (TS maximum of the
frequency)
— COM15 — PB 8 —
