Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
218 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
123 Property byte for byte 6 (maximum mean
value of the apparent power)
— Meter. fct. — PB 8 —
124 Property byte for byte 8 (minimum mean
value of the active power)
— Meter. fct. — PB 8 —
125 Property byte for byte 10 (maximum mean
value of the active power)
— Meter. fct. — PB 8 —
126 Property byte for byte 12 (minimum mean
value of the reactive power)
— Meter. fct. — PB 8 —
127 Property byte for byte 14 (maximum mean
value of the reactive power)
— Meter. fct. — PB 8 —
128 Property byte for byte 16 (TS minimum mean
value of the apparent power)
— COM15 — PB 8 —
129 Property byte for byte 24 (TS maximum mean
value of the apparent power)
— COM15 — PB 8 —
130 Property byte for byte 32 (TS minimum mean
value of the active power)
— COM15 — PB 8 —
131 Property byte for byte 40 (TS maximum mean
value of the active power)
— COM15 — PB 8 —
132 Property byte for byte 48 (TS minimum mean
value of the reactive power)
— COM15 — PB 8 —
133 Property byte for byte 56 (TS maximum mean
value of the reactive power)
— COM15 — PB 8 —
134 Property byte for byte 64 (TS minimum mean
value of the power factor)
— COM15 — PB 8 —
135 Property byte for byte 72 (TS max. mean
value of the power factor)
— COM15 — PB 8 —
