8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
207
8.6.6 Data set DS 68 data of the CubicleBUS module
The table below shows the content of data set 68 via which the outputs of the digital output
modules can be read and also controlled, and the system time can be read out. In addition, it
is possible to set the system time and also the outputs of the PROFIBUS interfaces for
switching breakers on or off.
The table below contains the data sets DS68: Data of the CubicleBUS module (length
45 bytes, read/write):
Table 8- 19 Content of data set 68
Byte Description Data
point
Source
WL
Source VL Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 System time of the circuit breaker 90 COM15 COM20 Time 64 —
12 Controls the outputs of the communication
module (e.g. switching the breaker)
19 COM15 COM20 Format
(19)
8 —
13 Reserved — — — — 8 —
14 Status of the outputs of the digital output
module 1
118 DO1 — Hex 8 —
15 Status of the outputs of the digital output
module 2
123 DO2 — Hex 8 —
16 Reserved — — — — 192 —
40 Property byte for byte 4 (system time of the
circuit breaker)
— COM15 COM20 PB 8 —
41 Property byte for byte 12 (controls the outputs
of the communication module (e.g. switching
the breaker))
— COM15 COM20 PB 8 —
42 Reserved — — — — 8 —
43 Property byte for byte 14 (status of the outputs
of the digital output module 1)
— DO1 — PB 8 —
44 Property byte for byte 15 (status of the outputs
of the digital output module 2)
— DO2 — PB 8 —
