3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
253
8.6.25 Data set DS 165 Identification comment
The table below shows data set 165 in which user-specific texts such as comments, plant
identifier, date and author can be stored in the SENTRON circuit breaker.
The table below contains the data sets DS165: Identification comment (length 194 bytes,
read/write):
Table 8- 38 Content of data set 165
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
0 Header; value 0x00 00 00 00 — COM15 COM20 — 32 —
4 User text (freely editable) 20 COM15 COM20 64 x char 512 —
68 Plant identifier (freely editable) 21 COM15 — 64 x char 512 —
132 Date (freely editable) 22 COM15 — Time 64 —
140 Author (freely editable) 23 COM15 — 30 x char 240 —
170 Reserved — — — — 160 —
190 Property byte for byte 4 — COM15 COM20 PB 8 —
191 Property byte for byte 68 — COM15 — PB 8 —
192 Property byte for byte 132 — COM15 — PB 8 —
193 Property byte for byte 140 — COM15 — PB 8 —
8.7 Formats
8.7.1 Formats of the data points
The different formats of the data points are described in this section. This includes the
description of the Motorola format used, e.g. "int" and "unsigned int", as well as, above all,
the description of special formats. A special format is, for example, the binary breakdown of
the data point that specifies the last tripping operation.
All available data points and the data set in which they are transferred over PROFIBUS have
been described on the preceding pages. In the "Format" column, an explanation is given of
which data type is referred to and how this content is to be interpreted. A distinction must be
made here between generally valid formats and special formats that are usually binary
coded.
