Data transfer to the PLC
7.1 Interface to S7-300 and control/diagnosis via PROFIBUS
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
151
Step 4 Creating the SENTRON WL/VL as a PROFIBUS node
For the precise steps, please refer to the Chapter Integration with the GSD file (Page 125)
Step 5
After all settings have been made, the created configuration still has to be saved and
compiled for use in the CPU. To do this, use the menu command
"Station > Save and Compile"
