Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
245
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
62 Undervoltage 277 Meter. fct. — unsigned
int
16 0
64 Delay time for undervoltage 278 Meter. fct. — unsigned c
har
8 0
65 Phase unbalance voltage 279 Meter. fct. — unsigned c
har
8 0
66 Delay time for voltage phase unbalance 280 Meter. fct. — unsigned c
har
8 0
67 Reserved — — — — 8 —
68 Overvoltage 281 Meter. fct. — unsigned
int
16 0
70 Delay time for overvoltage 282 Meter. fct. — unsigned c
har
8 0
71 Reserved — — — — 232 —
100 Property byte for byte 4 (active power in
normal direction)
— Meter. fct. — PB 8 —
101 Property byte for byte 6 (active power in
reverse direction)
— Meter. fct. — PB 8 —
102 Property byte for byte 8 (capacitive power
factor)
— Meter. fct. — PB 8 —
103 Property byte for byte 10 (inductive power
factor)
— Meter. fct. — PB 8 —
104 Property byte for byte 12 (delay time for
active power in normal direction)
— Meter. fct. — PB 8 —
105 Property byte for byte 13 (delay time for
active power in reverse direction)
— Meter. fct. — PB 8 —
106 Property byte for byte 14 (delay time for
capacitive power factor)
— Meter. fct. — PB 8 —
107 Property byte for byte 15 (delay time for
inductive power factor)
— Meter. fct. — PB 8 —
108 Property byte for byte 16 (overfrequency) — Meter. fct. — PB 8 —
109 Property byte for byte 17 (delay time for
overfrequency)
— Meter. fct. — PB 8 —
110 Property byte for byte 18 (underfrequency) — Meter. fct. — PB 8 —
111 Property byte for byte 19 (delay time for
underfrequency)
— Meter. fct. — PB 8 —
112 Property byte for byte 20 (current THD) — Meter. fct. — PB 8 —
113 Property byte for byte 21 (delay for current
THD)
— Meter. fct. — PB 8 —
114 Property byte for byte 22 (voltage THD) — Meter. fct. — PB 8 —
115 Property byte for byte 23 (delay time for
voltage THD)
— Meter. fct. — PB 8 —
116 Property byte for byte 24 (peak factor) — Meter. fct. — PB 8 —
117 Property byte for byte 26 (form factor) — Meter. fct. — PB 8 —
118 Property byte for byte 28 (delay time for peak
factor)
— Meter. fct. — PB 8 —
