Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
246 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
119 Property byte for byte 29 (delay time for form
factor)
— Meter. fct. — PB 8 —
120 Property byte for byte 30 (long-term mean
value for active power)
— Meter. fct. — PB 8 —
121 Property byte for byte 32 (long-term mean
value for apparent power)
— Meter. fct. — PB 8 —
122 Property byte for byte 34 (delay time for long-
term mean value of active power)
— Meter. fct. — PB 8 —
123 Property byte for byte 35 (delay time for long-
term mean value of apparent power)
— Meter. fct. — PB 8 —
124 Property byte for byte 36 (long-term mean
value for reactive power)
— Meter. fct. — PB 8 —
125 Property byte for byte 38 (reactive power in
normal direction)
— Meter. fct. — PB 8 —
126 Property byte for byte 40 (delay for long-term
mean value for reactive power)
— Meter. fct. — PB 8 —
127 Property byte for byte 41 (delay for reactive
power in normal direction)
— Meter. fct. — PB 8 —
128 Property byte for byte 42 (reactive power in
reverse direction)
— Meter. fct. — PB 8 —
129 Property byte for byte 44 (apparent power) — Meter. fct. — PB 8 —
130 Property byte for byte 46 (delay time for
reactive power in reverse direction)
— Meter. fct. — PB 8 —
131 Property byte for byte 47 (delay time for
apparent power)
— Meter. fct. — PB 8 —
132 Property byte for byte 48 (overcurrent) — Meter. fct. — PB 8 —
133 Property byte for byte 50 (current that flows
to ground)
— Meter. fct. — PB 8 —
134 Property byte for byte 52 (overcurrent in
neutral conductor)
— Meter. fct. — PB 8 —
135 Property byte for byte 54 (long-term mean
value for current)
— Meter. fct. — PB 8 —
136 Property byte for byte 56 (delay time for
overcurrent)
— Meter. fct. — PB 8 —
137 Property byte for byte 57 (delay time of
current that flows to ground)
— Meter. fct. — PB 8 —
138 Property byte for byte 58 (delay time for
overcurrent in neutral conductor)
— Meter. fct. — PB 8 —
139 Property byte for byte 59 (phase unbalance
current)
— Meter. fct. — PB 8 —
140 Property byte for byte 60 (delay time for
phase unbalance current)
— Meter. fct. — PB 8 —
141 Property byte for byte 61 (delay time for long-
term mean value for current)
— Meter. fct. — PB 8 —
142 Property byte for byte 62 (undervoltage) — Meter. fct. — PB 8 —
