Siemens SENTRON VL Series

Data library
8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
190 System Manual, 03/2011, A5E01051353-02
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
TS maximum of the neutral point voltage
phase L3
48 COM15 — Time 64 — DS73.112
TS minimum of the mean value of the
apparent power
57 COM15 — Time 64 — DS74.16
TS maximum of the mean value of the
apparent power
58 COM15 — Time 64 — DS74.24
TS minimum of the mean value of the
active power
49 COM15 — Time 64 — DS74.32
TS maximum of the mean value of the
active power
50 COM15 — Time 64 — DS74.40
TS minimum of the mean value of the
reactive power
51 COM15 — Time 64 — DS74.48
TS maximum of the mean value of the
reactive power
52 COM15 — Time 64 — DS74.56
TS minimum of the mean value of the
power factor
53 COM15 — Time 64 — DS74.64
TS maximum of the mean value of the
power factor
54 COM15 — Time 64 — DS74.72
TS minimum temperature in the control
cabinet
76 COM15 — Time 64 — DS77.4
TS maximum temperature in the control
cabinet
77 COM15 — Time 64 — DS77.12
TS minimum temperature in the circuit
breaker
78 COM15 — Time 64 — DS77.20
TS maximum temperature in the circuit
breaker
79 COM15 — Time 64 — DS77.28
TS minimum frequency 59 COM15 — Time 64 — DS76.8
TS maximum frequency 60 COM15 — Time 64 — DS76.16
TS minimum THD of current 61 COM15 — Time 64 — DS76.24
TS maximum THD of current 62 COM15 — Time 64 — DS76.32
TS minimum THD of voltage 63 COM15 — Time 64 — DS76.40
TS maximum THD of voltage 64 COM15 — Time 64 — DS76.48
TS minimum peak factor 65 COM15 — Time 64 — DS72.144
TS maximum peak factor 66 COM15 — Time 64 — DS72.152
TS minimum form factor 67 COM15 — Time 64 — DS72.160
TS maximum form factor 68 COM15 — Time 64 — DS72.168
