8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
215
Byte Description Data point Source
WL
Source
VL
Format Length
(bits)
Scaling
72 TS minimum of the neutral point voltage
phase L1
43 COM15 — Time 64 —
80 TS maximum of the neutral point voltage
phase L1
44 COM15 — Time 64 —
88 TS minimum of the neutral point voltage
phase 2
45 COM15 — Time 64 —
96 TS maximum of the neutral point voltage
phase L2
46 COM15 — Time 64 —
104 TS minimum of the neutral point voltage
phase L3
47 COM15 — Time 64 —
112 TS maximum of the neutral point voltage
phase L3
48 COM15 — Time 64 —
120 Reserved — — — — 240 —
150 Property byte for byte 0 (minimum phase-to-
phase voltage between phase L1 and L2)
— Meter. fct. — PB 8 —
151 Property byte for byte 2 (maximum phase-to-
phase voltage between phase L1 and L2)
— Meter. fct. — PB 8 —
152 Property byte for byte 4 (minimum phase-to-
phase voltage between phase L2 and L3)
— Meter. fct. — PB 8 —
153 Property byte for byte 6 (maximum phase-to-
phase voltage between phase L2 and L3)
— Meter. fct. — PB 8 —
154 Property byte for byte 8 (minimum phase-to-
phase voltage between phase L3 and L1)
— Meter. fct. — PB 8 —
155 Property byte for byte 10 (maximum phase-
to-phase voltage between phase L3 and L1)
— Meter. fct. — PB 8 —
156 Property byte for byte 12 (minimum of the
neutral point voltage phase L1)
— Meter. fct. — PB 8 —
157 Property byte for byte 14 (maximum of the
neutral point voltage phase L1)
— Meter. fct. — PB 8 —
158 Property byte for byte 16 (minimum of the
neutral point voltage phase L2)
— Meter. fct. — PB 8 —
159 Property byte for byte 18 (maximum of the
neutral point voltage phase L2)
— Meter. fct. — PB 8 —
160 Property byte for byte 20 (minimum of the
neutral point voltage phase L3)
— Meter. fct. — PB 8 —
161 Property byte for byte 22 (maximum of the
neutral point voltage phase L3)
— Meter. fct. — PB 8 —
162 Property byte for byte 24 (TS minimum
phase-to-phase voltage between phase L1
and L2)
— COM15 — PB 8 —
163 Property byte for byte 32 (TS maximum
phase-to-phase voltage between phase L1
and L2)
— COM15 — PB 8 —
164 Property byte for byte 40 (TS minimum
phase-to-phase voltage between phase L2
and L3)
— COM15 — PB 8 —
