8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
216 System Manual, 03/2011, A5E01051353-02
Byte Description Data point Source
WL
Source
VL
Format Length
(bits)
Scaling
165 Property byte for byte 48 (TS maximum
phase-to-phase voltage between phase L2
and L3)
— COM15 — PB 8 —
166 Property byte for byte 56 (TS minimum
phase-to-phase voltage between phase L3
and L1)
— COM15 — PB 8 —
167 Property byte for byte 64 (TS maximum
phase-to-phase voltage between phase L3
and L1)
— COM15 — PB 8 —
168 Property byte for byte 72 (TS minimum of the
neutral point voltage phase L1)
— COM15 — PB 8 —
169 Property byte for byte 80 (TS maximum of
the neutral point voltage phase L1)
— COM15 — PB 8 —
170 Property byte for byte 88 (TS minimum of the
neutral point voltage phase 2)
— COM15 — PB 8 —
171 Property byte for byte 96 (TS maximum of
the neutral point voltage phase L2)
— COM15 — PB 8 —
172 Property byte for byte 104 (TS minimum of
the neutral point voltage phase L3)
— COM15 — PB 8 —
173 Property byte for byte 112 (TS maximum of
the neutral point voltage phase L3)
— COM15 — PB 8 —
