Siemens SENTRON VL Series

Data library
8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
196 System Manual, 03/2011, A5E01051353-02
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
Delay time for active power in reverse
direction
286 Meter. fct. — unsigned
char
8 0 DS130.13
Power factor, capacitive 287 Meter. fct. — signed int 16 – 3 DS130.8
Delay time for power factor, capacitive 288 Meter. fct. — unsigned
char
8 0 DS130.14
Power factor, inductive 289 Meter. fct. — signed int 16 – 3 DS130.10
Delay time for power factor, inductive 290 Meter. fct. — unsigned
char
8 0 DS130.15
Long-time mean value of active power 291 Meter. fct. — unsigned
int
16 0 DS130.30
Delay time for long-term mean value of
active power
292 Meter. fct. — unsigned
char
8 0 DS130.34
Long-time mean value of apparent
power
293 Meter. fct. — unsigned
int
16 0 DS130.32
Delay time for long-term mean value of
apparent power
294 Meter. fct. — unsigned
char
8 0 DS130.35
Long-time mean value of reactive power 295 Meter. fct. — unsigned
int
16 0 DS130.36
Delay time for long-term mean value of
reactive power
296 Meter. fct. — unsigned
char
8 0 DS130.40
Reactive power in normal direction 297 Meter. fct. — unsigned
int
16 0 DS130.38
Delay time for reactive power in normal
direction
298 Meter. fct. — unsigned
char
8 0 DS130.41
Reactive power in reverse direction 299 Meter. fct. — unsigned
int
16 0 DS130.42
Delay time for reactive power in reverse
direction
300 Meter. fct. — unsigned
char
8 0 DS130.46
Apparent power 301 Meter. fct. — unsigned
int
16 0 DS130.44
Delay time for apparent power 302 Meter. fct. — unsigned
char
8 0 DS130.47
Overfrequency 303 Meter. fct. — unsigned
char
8 0 DS130.16
Delay time for overfrequency 304 Meter. fct. — unsigned
char
8 0 DS130.17
Underfrequency 305 Meter. fct. — unsigned
char
8 0 DS130.18
Delay time for underfrequency 306 Meter. fct. — unsigned
char
8 0 DS130.19
THD current 319 Meter. fct. — unsigned
char
8 0 DS130.20
Delay time for THD current 320 Meter. fct. — unsigned
char
8 0 DS130.21
THD voltage 321 Meter. fct. — unsigned
char
8 0 DS130.22
