Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
202 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
221 Property byte for byte 60 (event log of the last
10 events with time)
— COM15 COM20 PB 8 —
222 Property byte for byte 180 (status of the
connected PROFIBUS)
— COM15 COM20 PB 8 —
223 Property byte for byte 181 (controls the
commands/functions (e.g. delete/reset
min./max. values) of the communication
module)
— COM15 COM20 PB 8 —
224 Property byte for byte 182 (controls the
outputs of the communication module (e.g.
switching the breaker))
— COM15 COM20 PB 8 —
225 Property byte for byte 183
(shows the phase with maximum load)
— ETU ETU PB 8 —
226 Property byte for byte 184
(mean value of the power factor)
— Meter. fct. — PB 8 —
227 Property byte for byte 186 (current of the
phase with maximum load)
— ETU ETU PB 8 —
228 Property byte for byte 188 (time until
presumed overload trip)
— ETU — PB 8 —
229 Property byte for byte 190
(current in neutral conductor)
— ETU ETU PB 8 —
230 Property byte for byte 192
(current that flows to ground)
— ETU ETU PB 8 —
231 Property byte for byte 194 (system time of the
circuit breaker)
— COM15 COM20 PB 8 —
232 Property byte for byte 202 (position of the
circuit breaker in the frame)
— COM15 COM20 PB 8 —
233 Property byte for byte 203 (status of the circuit
breaker (on/off/charged, etc.))
— BSS COM20 PB 8 —
234 Property byte for byte 204 (overload
parameter I
R
parameter set A)
— ETU ETU PB 8 —
235 Property byte for byte 206 (overload
parameter I
R
parameter set B)
— ETU — PB 8 —
236 Property byte for byte 208
(rating plug)
— ETU ETU PB 8 —
237 Property byte for byte 210
(active parameter set)
— ETU — PB 8 —
