Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
237
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
78 Property byte for byte 14 (active power in normal
direction)
— Meter.
fct.
— PB 8 —
79 Property byte for byte 16 (active power in reverse
direction)
— Meter.
fct.
— PB 8 —
80 Property byte for byte 18 (delay time for active
power in normal direction)
— Meter.
fct.
— PB 8 —
81 Property byte for byte 19 (delay for active power
in reverse direction)
— Meter.
fct.
— PB 8 —
82 Property byte for byte 20 (normal direction of
incoming supply)
— Meter.
fct.
— PB 8 —
83 Property byte for byte 21 (direction of rotation of
phase)
— Meter.
fct.
— PB 8 —
84 Property byte for byte 22 (underfrequency) — Meter.
fct.
— PB 8 —
85 Property byte for byte 24 (delay for
overfrequency)
— Meter.
fct.
— PB 8 —
86 Property byte for byte 25 (delay for
underfrequency)
— Meter.
fct.
— PB 8 —
87 Property byte for byte 26 (overfrequency) — Meter.
fct.
— PB 8 —
88 Property byte for byte 28 (THD of current) — Meter.
fct.
— PB 8 —
89 Property byte for byte 29 (delay time of THD of
current)
— Meter.
fct.
— PB 8 —
90 Property byte for byte 30 (THD of voltage) — Meter.
fct.
— PB 8 —
91 Property byte for byte 31 (delay time of THD of
voltage)
— Meter.
fct.
— PB 8 —
92 Property byte for byte 32 (voltage unbalance) — Meter.
fct.
— PB 8 —
93 Property byte for byte 33 (delay time for voltage
unbalance)
— Meter.
fct.
— PB 8 —
94 Property byte for byte 34 (undervoltage) — Meter.
fct.
— PB 8 —
95 Property byte for byte 36 (overvoltage) — Meter.
fct.
— PB 8 —
96 Property byte for byte 38 (delay time for
undervoltage)
— Meter.
fct.
— PB 8 —
97 Property byte for byte 39 (delay time for
overvoltage)
— Meter.
fct.
— PB 8 —
98 Property byte for byte 40 (reserved) — Meter.
fct.
— PB 8 —
99 Property byte for byte 41 (current unbalance) — Meter.
fct.
ETU PB 8 —
100 Property byte for byte 42 (delay time for current
unbalance)
— Meter.
fct.
— PB 8 —
