Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
241
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
70 Rated current of the external g transformer 102 ETU — unsigned
int
16 0
72 Reserved — — — — 208 —
98 Property byte for byte 70 (rated current of
external g transformer)
— ETU — PB 8 —
99 Property byte for byte 68 (time lag class
(SENTRON VL LCD ETU40M only))
— ETU ETU PB 8 —
100 Property byte for byte 4 (overload parameter
I
R
parameter set A (PS A))
— ETU ETU PB 8 —
101 Property byte for byte 6 (Overload protection
neutral conductor I
N
PS A (WL))
— ETU — PB 8 —
102 Property byte for byte 8 (time lag class t
R
PS
A)
— ETU ETU PB 8 —
103 Property byte for byte 10 (short-circuit
protection instantaneous I
i
PS A)
— ETU ETU PB 8 —
104 Property byte for byte 12 (short-circuit
protection delayed I
sd
PS A)
— ETU ETU PB 8 —
105 Property byte for byte 14 (delay time short-
circuit protection t
sd
PS A)
— ETU ETU PB 8 —
106 Property byte for byte 16 (ground-fault
protection I
g
PS A)
— ETU ETU PB 8 —
107 Property byte for byte 18 (delay time for
ground fault t
g
PS A)
— ETU ETU PB 8 —
108 Property byte for byte 20 (ground fault alarm
I
g2
PS A)
— ETU — PB 8 —
109 Property byte for byte 22 (delay time for
ground fault alarm t
g2
PS A)
— ETU — PB 8 —
110 Property byte for byte 24 (I
2
t characteristic for
delayed short-circuit protection PS A)
— ETU ETU PB 8 —
111 Property byte for byte 25 (I
2
t characteristic for
ground-fault protection PS A)
— ETU ETU PB 8 —
112 Property byte for byte 26 (I
4
t characteristic for
overload protection PS A)
— ETU — PB 8 —
113 Property byte for byte 27 (thermal memory
PS A)
— ETU ETU PB 8 —
114 Property byte for byte 28 (phase loss
sensitivity PS A)
— ETU — PB 8 —
115 Property byte for byte 30 (cooling time
constant PS A)
— ETU — PB 8 —
116 Property byte for byte 32 (overload parameter
I
R
parameter set B (PS B))
— ETU — PB 8 —
117 Property byte for byte 34 (overload protection
neutral conductor I
N
PS B)
— ETU — PB 8 —
118 Property byte for byte 36 (time lag class t
R
PS
B)
— ETU — PB 8 —
119 Property byte for byte 38 (short-circuit
protection instantaneous I
i
PS B)
— ETU — PB 8 —
