8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
249
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
22 Property byte for DS128.30 (THD of current) — Meter. fct. — PB 8 —
23 Property byte for DS128.32 (voltage
unbalance)
— Meter. fct. — PB 8 —
24 Property byte for DS128.34 (undervoltage) — Meter. fct. — PB 8 —
25 Property byte for DS128.36 (overvoltage) — Meter. fct. — PB 8 —
26 Property byte for DS128.41 (current
unbalance)
— Meter. fct. ETU PB 8 —
27 Property byte for DS130.4 (active power in
normal direction)
— Meter. fct. — PB 8 —
28 Property byte for DS130.6 (active power in
reverse direction)
— Meter. fct. — PB 8 —
29 Property byte for DS130.8 (capacitive power
factor)
— Meter. fct. — PB 8 —
30 Property byte for DS130.10 (inductive power
factor)
— Meter. fct. — PB 8 —
31 Property byte for DS130.16 (overfrequency) — Meter. fct. — PB 8 —
32 Property byte for DS130.18 (underfrequency) — Meter. fct. — PB 8 —
33 Property byte for DS130.20 (current THD) — Meter. fct. — PB 8 —
34 Property byte for DS130.22 (voltage THD) — Meter. fct. — PB 8 —
35 Property byte for DS130.24 (peak factor) — Meter. fct. — PB 8 —
36 Property byte for DS130.26 (form factor) — Meter. fct. — PB 8 —
37 Property byte for DS130.30 (long-term mean
value for active power)
— Meter. fct. — PB 8 —
38 Property byte for DS130.32 (long-term mean
value for apparent power)
— Meter. fct. — PB 8 —
39 Property byte for DS130.36 (long-term mean
value for reactive power)
— Meter. fct. — PB 8 —
40 Property byte for DS130.38 (reactive power in
normal direction)
— Meter. fct. — PB 8 —
41 Property byte for DS130.42 (reactive power in
reverse direction)
— Meter. fct. — PB 8 —
42 Property byte for DS130.44 (apparent power) — Meter. fct. — PB 8 —
43 Property byte for DS130.48 (overcurrent) — Meter. fct. — PB 8 —
44 Property byte for DS130.50
(current that flows to ground)
— Meter. fct. — PB 8 —
45 Property byte for DS130.52 (overcurrent in
neutral conductor)
— Meter. fct. — PB 8 —
46 Property byte for DS130.54 (long-term mean
value for current)
— Meter. fct. — PB 8 —
47 Property byte for DS130.59 (phase unbalance
current)
— Meter. fct. — PB 8 —
48 Property byte for DS130.62 (undervoltage) — Meter. fct. — PB 8 —
49 Property byte for DS130.65 (phase unbalance
voltage)
— Meter. fct. — PB 8 —
50 Property byte for DS130.68 (overvoltage) — Meter. fct. — PB 8 —
