Data library
8.7 Formats
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
277
Table 8- 85 Format (412) "Trip unit type" 3WL
Byte Value IEC / UL Meaning
0 4 IEC ETU45B
0 5 IEC ETU45B with display
0 6 IEC ETU45B with ground fault
0 7 IEC ETU45B with display and ground fault
0 13 IEC ETU76B
0 14 IEC ETU76B with ground fault
0 17 UL ETU748
0 18 UL ETU748 with display
0 19 UL ETU748 with ground fault
0 20 UL ETU748 with display and ground fault
0 22 UL ETU776
0 23 UL ETU745
Table 8- 86 Format (412) "Trip unit type" 3VL
Byte Value IEC / UL Meaning
0 15 IEC LCD ETU
0 16 IEC LCD ETU with motor protection
0 27 IEC ETU with "LI" protection
0 28 IEC ETU with "LS" protection
0 29 IEC ETU with motor protection and adjustable trip class
0 30 UL ETU with "LI" protection
0 31 UL ETU with "LS" protection
0 32 UL ETU with motor protection
0 33 IEC LCD ETU with "LSI" protection and ground fault signal
0 34 IEC ETU with motor protection and "LI" protection
0 35 UL LCD ETU with "LSI" protection and ground fault signal
0 37 UL LCD ETU with "LSI" protection and ground fault signal only
