3WL air circuit breakers
3.5 External CubicleBUS modules
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
79
Switch position "P"
If the rotary coding switch is at the "P" position, the measured values of the power are output
via the four channels:
A01: Active power phase P
L1
A02: Active power phase P
L2
A03: Active power phase P
L3
A04: Total apparent power S
total
To calculate the full-scale deflection value of the active power per phase, the value of the
rating plug must be multiplied by the rated voltage of the system. The full-scale deflection
value is then subdivided into a value range shown in the table below.
For the total apparent power and the total active power (position f), the calculated value still
has to be multiplied by 3 before the full-scale deflection value can be read from the table.
The table below gives the value ranges for power [W/VA]:
Table 3- 20 Value ranges for power [W/VA] on the analog output module
From To Full-scale deflection value
0 49.999 50.000
50.000 99.999 100.000
100.000 199.999 200.000
200.000 299.999 300.000
300.000 399.999 400.000
400.000 499.999 500.000
500.000 999.999 1.000.000
1.000.000 1.999.999 2.000.000
2.000.000 2.999.999 3.000.000
3.000.000 4.999.999 5.000.000
5.000.000 9.999.999 10.000.000
10.000.000 19.999.999 20.000.000
20.000.000 ∞ 30.000.000
Example:
I
R
= 1600 A, rated voltage = 400 V; ⇒ Full-scale deflection value = 1,000,000 W
