ARC
73
Siemens Building Technologies
Fire Safety & Security Products 07.2009
13.3 Protocol
The following protocols are available:
NOTE
The protocols depending on the unit version.
Telim 6 digits Open protocol; 8 values
Telenot 6 digits Open protocol; 8-15 values
Ademco Contact ID 4 digits Closed protocol.
NOTE
If a transmssion line of a syntchetic input (e.g. BA Partition
1) is enabled, all physical BA inputs linked to partition 1 are
automatically internally set to tranmission, even if the
tranmission of according physical inputs are disabled.
Ademco Express
SIA level 1 6 digits Closed protocol
SIA level 2 6 digits Closed protocol
Vocal No digits Message 1-6
Cesa 200 Bds 5 digits Open protocol; 0 - 99 values
Seriee 4 digits Low battery, Full set, Test, code alarm
Stratel 8 digits Open protocol; 0 - 99 values
Robofon 6 digits
Surtec DTMF 5 digits
Scantronic 6 digits Open protocol; 16 values
4 plus 2 4 digits
WITLINK V23 8 digits
Only for ARC 1
Cesa extended 8 digits SI 120/220
Customer number partition
1
All events from partition 1 and virtual partition 3 and the system alarms (battery fault, automatic test call,
…) can be transmitted with this number.
Customer number partition
2
All events from partition 2 can be transmitted with this number.
