Overvoltage Alarm Time (Hours and Minutes)
(Address 8) This register contains the alarm time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Overvoltage Alarm Time (Month and Date)
(Address 9) This register contains the alarm time in month and date.
Refer to Last Reset Time (Month and Date), Page 144.
Overvoltage Alarm Time (Year)
(Address 10) This register contains the overvoltage alarm time in years.
Refer to Last Reset Time (Year), Page 145.
Overvoltage Warning Type
(Address 11) This register defines the phase in which the overvoltage warning is occurred.
Bit 15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used V
3
V
2
V
1
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit –
Range –
Overvoltage Warning Time (Milliseconds)
(Address 12) This register contains the overvoltage warning time in milliseconds.
Refer to Last Reset Time (Milliseconds), Page 144.
Overvoltage Warning Time (Hours and Minutes)
(Address 13) This register contains the overvoltage warning time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Overvoltage Warning Time (Month and Date)
(Address 14) This register contains the overvoltage warning time in month and date.
Refer to Last Reset Time (Month and Date), Page 144.
Overvoltage Warning Time (Year)
(Address 15) This register contains the overvoltage warning time in years.
Refer to Last Reset Time (Year), Page 145.
Undervoltage Alarm Type
(Address 16) This register defines the phase in which the undervoltage alarm is occurred.
Bit
15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used V
3
V
2
V
1
Modbus Registers
B.6 Register-Type Data – Analog Input Registers
146 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
