2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit –
Range –
Undervoltage Alarm Time (Milliseconds)
(Address 17) This register contains the undervoltage alarm time in milliseconds.
Refer to Last Reset Time (Milliseconds), Page 144.
Undervoltage Alarm Time (Hours and Minutes)
(Address 18) This register contains the undervoltage alarm time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Undervoltage Alarm Time (Month and Date)
(Address 19) This register contains the undervoltage alarm time in month and date.
Refer to Last Reset Time (Month and Date), Page 144.
Undervoltage Alarm Time (Year)
(Address 20) This register contains the undervoltage alarm time in years.
Refer to Last Reset Time (Year), Page 145.
Undervoltage Warning Type
(Address 21) This register defines the phase in which the undervoltage warning is occurred.
Bit
15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used V
3
V
2
V
1
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit –
Range –
Undervoltage Warning Time (Milliseconds)
(Address 22) This register contains the undervoltage warning time in milliseconds.
Refer to Last Reset Time (Milliseconds), Page 144.
Undervoltage Warning Time (Hours and Minutes)
(Address 23) This register contains the undervoltage warning time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Undervoltage Warning Time (Month and Date)
(Address 24) This register contains the undervoltage warning time in month and date.
Refer to Last Reset Time (Month and Date), Page 144.
Undervoltage Warning Time (Year)
(Address 25) This register contains the undervoltage warning time in years.
Modbus Registers
B.6 Register-Type Data – Analog Input Registers
SICAM, Feeder Condition Monitor, Manual 147
E50417-H8940-C580-A4, Edition 03.2019
