Refer to Last Reset Time (Year), Page 145.
Overcurrent Alarm Type
(Address 26) This register defines the phase in which the overcurrent alarm is occurred.
Bit 15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used I
3
I
2
I
1
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit –
Range –
Overcurrent Alarm Time (Milliseconds)
(Address 27) This register contains the overcurrent alarm time in milliseconds.
Refer to Last Reset Time (Milliseconds), Page 144.
Overcurrent Alarm Time (Hours and Minutes)
(Address 28) This register contains the overcurrent alarm time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Overcurrent Alarm Time (Month and Date)
(Address 29) This register contains the overcurrent alarm time in month and date.
Refer to Last Reset Time (Month and Date), Page 144.
Overcurrent Alarm Time (Year)
(Address 30) This register contains the overcurrent alarm time in years.
Refer to Last Reset Time (Year), Page 145.
Overcurrent Warning Type
(Address 31) This register defines the phase in which the overvoltage warning is occurred.
Bit
15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used I
3
I
2
I
1
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Overcurrent Warning Time (Milliseconds)
(Address 32) This register contains the overcurrent warning time in milliseconds.
Refer to Last Reset Time (Milliseconds), Page 144.
Overcurrent Warning Time (Hours and Minutes)
(Address 33) This register contains the overcurrent warning time in hours and minutes.
Refer to Last Reset Time (Hours and Minutes), Page 144.
Modbus Registers
B.6 Register-Type Data – Analog Input Registers
