112 •
••
• 6 - Programming Simatic 505 SoftShop
data of the selected program on disk to the data in the controller (online)
or offline.
To perform a File Program Compare you must first have an opened
online or offline program see Chapter 3 Open an Existing Logic
Program Offline or Online.
Select File Program Compare from the File menu.
Result: The File Program Compare window appears (Figure 6.09d).
Figure 6.09d
1. Click the Browse button to locate the disk file to compare or
type in the file extension and file name in the Compare File
box.
2. Next, enter the Maximum mismatches per category. Maximum
mismatches per category allows you to abort the compare
process if the number of mismatches exceeds the number
entered in the Maximum mismatches per category selection
box.
3. Now click on the check boxes that correspond to the items you
want to compare. For each of the V or K memory address, you
can also choose the range for the comparison.
4. Then enter a result file path and name in the Result File box if
the results of the compare are to be saved to a file.
5. Click OK to start the compare process.
NOTE
If there are more than one program opened, the File Program
Compare compares the program in the active window.
