Print to a Text File
1. To print to a text file select Output To Text File from the File
menu. The Result: The Print Output to Text File dialog box
appears (Figure 3.19b). See Printing Logic Programs for dialog
box selections.
2. Once selections are made select OK.
3. Enter a file name to save to and select OK
Figure 3.19b
Editing Features
505 SoftShop uses a number of timesaving editing features to help you
complete your programming tasks. These include:
• Cut
• Copy
• Paste
• Paste With Rewire
• Undo
• Clear
• Delete
• Insert
The most frequently used editing features are Cut, Copy, and Paste. Use
these commands to quickly copy logic and documentation to either
another location in the same program or another program. The list below
describes Cut, Copy, and Paste differences.
