38 •
••
• 3 - 505 SoftShop Basics
Click the All check box to print the entire range of items. To print a
selection, deselect the All check box and enter a range in the associated
edit box.
The following can be individually turned on and off to be included with
Cross reference printout:
• Tags
• Descriptions Status Words
• Timer Variable
• Drum Variables
• One Shots Shift Registers
• Tables-Moves
• SF Error Codes
• Loop Variables
• Alarm Variables
• G-Mem/VMM/VMS
To include Addresses Used Table with the Cross-reference print out
select the appropriate check box under Include.
1. Click on the Doc Font button to change the Tag, Description, and
Comments printout font of the active program.
Result: The Font dialog box appears.
2. Choose a new font, font style, or font size. Notice that you can see a
sample of the font in the Sample box.
3. Click OK in the Font dialog box to save your changes or click Cancel
to cancel changes.
Result: The Print Cross-reference dialog box appears.
NOTE
The print selection options are stored when saving a program.
