174 •
••
• 9 - PID Loops Simatic 505 SoftShop
1. To Document a PID Loop, Click on PID Loop... from the View
menu or (Alt+V, P). The PID Loop Directory dialog box
appears (Figure 9.1a). The dialog box shows the Loop Mode,
Loop number (1-64), Loop Title, and Enable/Disable state.
2. Select the PID Loop number that you want to document by using
the left mouse button or the Arrow keys on the keyboard. Click
on the dialog box Document button or use the keyboard to Tab
to the document button and press Enter or (Alt+O). The
following dialog box appears (Figure 9.11).
Figure 9.11
