PLC WorkShop for Simatic TI505 FTLogger •
••
• 1
FTLogger
FTLogger Overview
FTLogger collects data from multiple PLC devices to selected database
files. Addresses are entered in a spreadsheet format with up to 1,000
addresses per log window. Data is logged based on a specific time frame
deadband or event.
Creating a Log Window
To create a new Log Window, perform the following steps:
1. Launch FTLogger
2. Click
on the Toolbar or select New Program from the File
menu.
Figure 1
3. Enter a unique name, up to 128 characters, for the new Logger
Window spreadsheet in the Name field.
