Simatic 505 SoftShop 6 - Programming •
••
• 91
Mnemonic Instruction
it.
If the TISOFT mode is turned on in the program setup (see Ladder
options under LOGIC tab in Program Setup) the following list of the
function key alternatives and the CTRL/ALT functions are available.
Key Comment
Y COILS Valid if cursor is in an output
column
C COILS Valid if cursor is in an output
column
WY COILS Valid if cursor is in an output
column
V COILS Valid if cursor is in an output
column
G COILS Valid if cursor is in an output
column
W COILS Valid if cursor is in an output
column
X CONTACTS Valid if cursor is in an
input column
Y CONTACTS Valid if cursor is in an
input column
C CONTACTS Valid if cursor is in an
input column
WX/WY CONTACTS Valid if cursor is in an
input column
V CONTACTS Valid if cursor is in an
input column
K CONTACTS Valid if cursor is in an
input column
G CONTACTS Valid if cursor is in an
input column
W CONTACTS Valid if cursor is in an
input column
/ Open/closed contact/coil toggle
DEL Delete current element
END Moves to last column/row 1 of
current rung
ENTER Edit: moves to next row, current
rung, or to next rung
Display: moves to next row or rung
= Equal-to Relational Contact
ESC Deletes current address and puts you
into edit mode for address.
