SIMATIC Box PC 627
Operating Instructions, Release 05/2006, A5E00362052-03
14-1
Technical Data
14
14.1 14.1 General Specifications
General technical data
Order numbers 6ES7647-6Axxx-xxxx
Dimensions Without DVD/CD-RW: 297x267x80 (WxHxD in mm)
With DVD/CD-RW: 297x267x100
Weight approx. 7 kg
Supply voltage (AC) Nominal 100 - 240 V AC (-15% / +10%) (autorange)
Supply voltage (DC) Nominal 24 V DC (-15% / + 20%), SELV
Input current AC Steady-state current up to 2.3 A (on start-up, up to 50A for
1 ms)
Input current DC Continuous current to 9 A (to 14 A for 30 ms at startup)
Line voltage frequency 50 - 60 Hz (47 to 63 Hz)
Transient current interruption according
to Namur
min.20 ms (at 93 to 264 V)
(max. 10 events per hour; min. recovery time 1 s)
max. power consumption AC and DC 190 W / 210 W
max. current output +5 V / 16.5 A
*
(18.5 W peak)
+3.3 V / 8.5 A
*
*
total of 90 W permitted
+12 V / 6.5 A (8 A peak)
–12 V / 0.3 A
The total sum of all voltages is max. 150 W.
Noise emission < 55 dB(A) according to DIN 45635-1
Degree of protection IP 20
Safety
Protection class Protection class I to IEC 61140
Safety regulations AC: EN 60950-1; UL60950-1; CAN/CSA C22.2
No 60950-1-03
DC: EN 61131-2; UL508; CSA C22.2 No 142
Electromagnetic compatibility (EMC)
Emitted interference EN 55022 Class B, EN 61000-3-2 Class D
EN 61000-3-3; FCC Class A
Noise immunity:
Mains borne disturbance variables on
supply lines
± 2 kV, (according to IEC 61000-4-4; Burst)
± 1 kV; (according to IEC 61000-4-5; Surge symm)
± 2 kV; (according to IEC 61000-4-5; Surge asymm)
Noise immunity on signal lines ± 1 kV;(according to IEC 61000-4-4; Burst; Length < 5 m)
± 2 kV; (according to IEC 61000-4-4; Burst; Length > 5 m)
± 2 kV; (according to IEC 61000-4-5; Surge; Length > 30m)
